Allen-Bradley 1794-OB32P, Flex I/O Electronically Protected Discrete Output Module

Manufacturer- Allen Bradley
Product Type- Flex I/O Digital DC Output Module
Product Line- Flex I/O 1794
Part Number- 1794-OB32P
Weight- 0.25 lbs (0.11 kg)
Output Current Rating- 14.0 A max per module (6 A total for channels 0...15; 8 A total for channels 16...31)
Product Description- Flex IO DC Output Module
Number of Outputs- Thirty-Two (32) Channels
Output circuit type- Sourcing
Terminal base- 1794-TB32 and 1794-TB32S
ON state Voltage, min- 10VDC
ON state Voltage, max.- 31.2VDC
ON state Voltage, nom- 24VDC
Enclosure- Open-type
Mounting- DIN Rail
Wire Size- Determined by installed terminal base
Operating Temperature- 0 to 55 C (32 to 131 F)
Storage Temperature- -40 to 85 C (-40 to 185 F)
Vibration- 5g @ 10 to 500 Hz
Operating Shock- 30 g
Outputs- 32 Sourcing Current
On-state Current max.- 500mA per Channel
On-state Voltage Drop max.- 0.5V DC
Off-state Leakage Current max.- 0.5mA
Isolation Voltage- 50V Continuous
Flexbus Current- 80mA @ 5V DC
Power Dissipation- 5.3W @ 31.2V DC max.
Thermal Dissipation- 18.1 BTU/hr. @ 31.2V DC max.
