LOYTEC LINX-101, L-INX Automation Server

LOYTEC LINX-101, L-INX Automation Server

The L-INX Automation Servers LINX‑100 and LINX-101 can host user specific graphical pages and can integrate physical I/Os through L-IOB I/O Modules via LIOB-FT or LIOB-IP. The powerful Automation Servers provide connectivity functions to concurrently integrate CEA-709 (LonMark Systems), Modbus, and M-Bus subsystems.
LonMark Systems can be integrated via IP-852 (Ethernet/IP) or TP/FT‑10. LINX‑100 Automation Servers feature an integrated Remote Network Interface (RNI) to access the TP/FT‑10 channel on the device via Ethernet/IP. LINX-101 Automation Servers feature a built-in IP-852 router providing the complete feature set of the corresponding L-IP devices. In addition, the L-INX Automation Servers provide connectivity to Modbus TCP via Ethernet/IP and to Modbus RTU via RS-485. M-Bus device integration needs an optional interface module. The gateway functionality allows data communication between all communication technologies available on the device. Different technology data points are mapped through Local Connections on the device. The mapping of different technology data points on distributed devices is supported by Global Connections. L-INX Automation Servers also support Smart Auto-Connect™ – the automatic generation of connections to substantially reduce engineering efforts and cost. All technology data points are automatically created as OPC XML-DA data points as well.

Availability: In stock

Excl. Tax: £1,131.78 Incl. Tax: £1,358.14

Qty:

LOYTEC LINX-101, L-INX Automation Server

Features:-
• System visualization via LWEB‑802/803
• Stores customized graphical pages
• Extension with physical inputs and outputs using L‑IOB I/O Modules (LIOB‑FT or LIOB‑IP852)
• Built-in OPC XML‑DA server
• Alarming, Scheduling, and Trending (AST™)
• Event-driven e-mail notification
• Compliant with CEA‑709, CEA‑852, and ISO/IEC 14908 standard (LonMark System)
• Supports TP/FT‑10 or IP-852 (Ethernet/IP)
• Support of dynamically created or static NVs
• Support of CEA‑709 user-defined NVs (UNVTs) and Configuration Properties (SCPTs, UCPTs)
• CEA‑709 Remote Network Interface (RNI) with 2 MNI devices (LINX‑100 only)
• Integrated IP‑852 to TP/FT‑10 Router (LINX‑101 only)
• M-Bus Master according to EN 13757-3, connection via optional M‑Bus Converter (L‑MBUS20 or L‑MBUS80)
• Modbus TCP and Modbus RTU (Master or Slave)
• Gateway functions including Smart Auto-Connect™
• Integrated web server for device configuration and monitoring data points
• Access to network statistics
• Configurable via Ethernet, or TP/FT‑10
• Dimensions (mm)- 107 x 100 x 60 (L x W x H), DIM009
• Installation- DIN rail mounting following DIN 43880, top hat rail EN 50022
• Power supply- 12-35 VDC / 12-24 VAC ±10 %, typ. 3 W
• Operating conditions- 0 °C to 50 °C, 10–90 % RH @ 50 °C, non condensing, degree of protection: IP40, IP20 (terminals)
• L‑IOB I/O Modules Up to 8 L‑IOB I/O Modules in any combination of type LIOB‑FT and LIOB‑IP852
• Remote Network Interface 1 RNI with 2 MNI devices (LINX‑100 only)
• CEA‑709 Router 1 (LINX‑101 only)
• Tools L‑INX/L-GATE Configurator

storage_Type	No
Manufacturer Part No	LINX-101, LINX101
Manufacturer	No
Datasheet	No
