Mistubishi GT2510-VTBD, Human Machine Interfaces

* Display device- TFT color LCD

* Screen size- 10.4"

* Display size- 211.2 (W) x 158.4 (H) mm, (8.31 (W) x 6.24 (H) inch)

* Number of displayed characters- 16-dot standard font: 40 characters x 30 lines (two-byte characters), 12-dot standard font: 53 characters x 40 lines (two-byte characters)

* Display color- 65536 colors

* Brightness adjustment- 32 levels

* Registrable number of screen- 4096

* Backlight- LED (not replaceable)

* Touch Panel:-

* Type- Analog resistive film

* Key size- Minimum 2 x 2 dots*9 (per key)

* Life- 1 million touches or more (operating force: 0.98 N or less)

* Battery:-

* Type- GT11-50BAT lithium battery

* Backup target- SRAM data, clock data, system status log data

* Life- Approx. 5 years (ambient temperature: 25°C)

* External dimensions- 303 (W) x 218 (H) x 52 (D) mm

* Panel cut dimensions- 289 (W) x 200 (H) mm

* Weight (excluding a fitting)- 2.1 kg
