Technical Key Specifications:-
Print Technology- Drop-on-demand Micro Piezo Inkjet Technology
Print Head- 1
Nozzle Configuration- 180 nozzles x 8 lines
Drop Mass Range (pl)- 3.5 to 35.2
Head Heights Low: 1.2 mm / High: 2.0 mm
Media Specifications:-
Max. Media Width- 1371 mm (53,97”)
Max. Print Width- 1361 mm (53,58”)
Max. Media Thickness- 0.3 / 1.3 mm *
Max. media thickness is specified per head
Media Measurements- Ø 150 mm / 2” & 3” / 19 kg
Standard non-motorised roll-off system
Media Drying System- Individually controlled pre-heater, fixer & dryer (30 - 50 °C)
Performance:-
High Quality (720 x 1440)- 3.9 m²/h
Quality (720 x 1080)- 6.0 m²/h
Quality Production (720 x 1080)- 7.9 m²/h
Production (720 x 720)- 11.8 m²/h
Speed Production (720 x 720)- 16.4 m²/h
Billboard (360 x 720)- 27.9 m²/h
Machine Measurements:-
Width x Depth x Height- 1916 x 685 x 1218 mm
Weight- 82.3 kg
| storage_Type | N/A |
|---|---|
| Manufacturer Part No | 1324X |
| Manufacturer | Mutoh |
| Datasheet | No |
